Features and Advantage
Designed to handle high inlet temperatures up to 80℃.
Demister water separator, 99+% efficiency dew point guarantee, much better than cyclone separator.
Environment friendly HFC refrigerants R134a and R407C.
High efficiency all-in-one heat exchanger design enable our dryers light weight and small foot print.Automatic refrigeration temperature control system maintains precise chilled air temperature.
Less point of welding, lower leakage risk.
Large pre-cooler & counter flow design, save energy up to 25%.
Rugged hermetically refrigeration compressor provide years of trouble free service.
Refrigeration side insulation to save energy.
Various power supply for option.
Technical Specification
| Model | Air Connection | Capacity m³/min | Power Supply | Absorbed Power (kW) | Dimension mm | Weight | |||
| m³/min | CFM | V/Ph/Hz | L | W | H | kg | |||
| ENLF-12-HT | Rc1/2" | 1.2 | 42 | 230/1/50 | 0.3 | 650 | 320 | 550 | 35 |
| ENLF-24-HT | Rc1" | 2.4 | 85 | 230/1/50 | 0.61 | 800 | 420 | 600 | 70 |
| ENLF-30-HT | Rc1" | 3 | 106 | 230/1/50 | 0.76 | 800 | 420 | 600 | 75 |
| ENLF-60-HT | Rc1-1/2" | 6 | 212 | 230/1/50 | 1.09 | 750 | 695 | 1260 | 125 |
| ENLF-80-HT | Rc1-1/2" | 8 | 282 | 230/1/50 | 1.45 | 750 | 695 | 1260 | 128 |
| ENLF-100-HT | Rc1-1/2" | 10 | 353 | 230/1/50 | 1.82 | 750 | 695 | 1260 | 133 |
| ENLF-120-HT | Rc2" | 12 | 424 | 230/1/50 | 2.18 | 1000 | 840 | 1450 | 165 |
| ENLF-150-HT | Rc2" | 15 | 530 | 230/1/50 | 2.73 | 1000 | 840 | 1450 | 175 |
