Water lubricated series air compressors are used in food, medical, chemical, bottle blowing and other equipment that have requirements for compressed air. It has the advantages of clean and oil-free compressed air, simple maintenance, lower cost, all parts of the machine are made of stainless steel, ensuring no rust, adopting integrated system design and operation, isothermal compression, higher volumetric efficiency, energy saving more.
Advantage:
1. Imported Japan technology.
2. Energy saving
3. accept customized low and high pressure
4. accept explosion-proof
5. stable quality
6. easy maintenance
7. with CE mark and testing report
NO. | Motor power | Flow rate (m³/min) | relaed working pressure (Mpa) | Cooling way | Cooling water volume（T/H) | lubrication oil （L） | voltage（V） | Length（mm） | Width（mm） | height（mm） |
inlet water temp.≦30℃ | option accpeted customized | A | B | C | ||||||
1 | 5.5 | 0.8 | 0.8 | water/air | 1.5 | 10 | 380/660/1140 | 800 | 800 | 1200 |
2 | 7.5 | 1.2 | 0.8 | water/air | 2 | 10 | 380/660/1140 | 800 | 800 | 1200 |
3 | 11 | 1.7 | 0.8 | water/air | 2.5 | 20 | 380/660/1140 | 1200 | 855 | 1335 |
4 | 15 | 2.2 | 0.8 | water/air | 2.5 | 26 | 380/660/1140 | 1200 | 855 | 1335 |
5 | 18.5 | 3 | 0.8 | water/air | 3.5 | 26 | 380/660/1140 | 1400 | 1010 | 1340 |
6 | 22 | 4 | 0.8 | water/air | 4 | 30 | 380/660/1140 | 1400 | 1010 | 1340 |
7 | 30 | 5 | 0.8 | water/air | 5 | 30 | 380/660/1140 | 1650 | 1180 | 1500 |
8 | 37 | 6.2 | 0.8 | water/air | 7 | 40 | 380/660/1140 | 1650 | 1180 | 1500 |
9 | 45 | 7.5 | 0.8 | water/air | 9 | 40 | 380/660/1140 | 1650 | 1180 | 1500 |
10 | 55 | 10 | 0.8 | water/air | 10 | 90 | 380/660/1140 | 1800 | 1360 | 1650 |
11 | 75 | 12.5 | 0.8 | water/air | 12 | 100 | 380/660/1140 | 1800 | 1360 | 1650 |
12 | 90 | 16 | 0.8 | water/air | 18 | 100 | 380/660/1140 | 1800 | 1360 | 1650 |
13 | 110 | 20 | 0.8 | water/air | 20 | 120 | 380/660/1140 | 2200 | 1550 | 1800 |
14 | 132 | 22.5 | 0.8 | water/air | 24 | 120 | 380/660/1140 | 2200 | 1550 | 1800 |
15 | 160 | 27.5 | 0.8 | water/air | 30 | 120 | 380/660/1140 | 2200 | 1550 | 1800 |
16 | 185 | 32 | 0.8 | water/air | 35 | 160 | 380/660/1140 | 2700 | 1850 | 1800 |
17 | 200 | 34 | 0.8 | water/air | 38 | 160 | 380/660/1140 | 3000 | 1850 | 2100 |
18 | 220 | 37 | 0.8 | water/air | 42 | 200 | 380/660/1140 | 3000 | 1850 | 2100 |
19 | 250 | 42 | 0.8 | water/air | 47 | 200 | 380/660/1140 | 3000 | 1850 | 2100 |
