Security and Reliability
All series dryer have been passed the newest “CE” certification by European Union.
Evaporator can be leak test separately, greatly reduced leaking risk.
Main parts are using world famous brand with reliable performance.
Wit h many overload protection and shut down protection.
Energy Saving and Environmental Protection
Heat exchanger is following Europe and the United State advanced plate-fin structure, and highly heat-efficiency.
The pre-cooler reclaim nearly 90% compressed air, and greatly reduces the evaporator load. so the power consumption of the refrigerant compressor is very low, is about 70% of the regular one.
The inlet and outlet temperature difference of pre-cooler is 5-8℃, more then twice better than the similar products, Outlet compressed air relative humidity is low, the below air pipe surface without Condensation phenomenon.
Friendly refrigerant is adopted for all series Enair air dryers .
Various Control Options
Standard model with fault alarm indicator;
As customer require we will use SMC or PLC or touch screen;
RS485 I/O, Profibus protocol, Modbus protocol and Ethernet are available on customer request .
Models specification ( Not Including All )
Model | Air | Capacity | Dimensions (in) | Weight | Power supply | Rated power | Recommended | Recommended | ||||
m³/min | cfm | L | W | H | kg | V/Ph/Hz | KW | HP | ||||
ENLF-06-SSD | Rc1/2" | 0.6 | 21 | 20 | 10 | 20 | 25 | 220-230/1/50 | 0.23 | 0.31 | ENG-AO-0017G/V2 | ENG-AA-0017G/V2 |
ENLF-09-SSD | Rc1/2" | 0.9 | 32 | 20 | 10 | 20 | 25 | 220-230/1/50 | 0.26 | 0.35 | ENG-AO-0017G/V2 | ENG-AA-0017G/V2 |
ENLF-12-SSD | Rc1/2" | 1.2 | 43 | 24 | 12 | 20 | 30 | 220-230/1/50 | 0.40 | 0.54 | ENG-AO-0030G/V2 | ENG-AA-0030G/V2 |
ENLF-15-SSD | Rc1/2" | 1.5 | 54 | 24 | 12 | 20 | 30 | 220-230/1/50 | 0.45 | 0.60 | ENG-AO-0030G/V2 | ENG-AA-0030G/V2 |
ENLF-18-SSD | Rc1/2" | 1.8 | 64 | 24 | 12 | 20 | 30 | 220-230/1/50 | 0.46 | 0.62 | ENG-AO-0030G/V2 | ENG-AA-0030G/V2 |
ENLF-24-SSD | Rc3/4" | 2.4 | 86 | 30 | 14 | 22 | 50 | 220-230/1/50 | 0.47 | 0.63 | ENG-AO-0058G/V2 | ENG-AA-0058G/V2 |
ENLF-30-SSD | Rc3/4" | 3.0 | 107 | 30 | 14 | 22 | 50 | 220-230/1/50 | 0.49 | 0.66 | ENG-AO-0058G/V2 | ENG-AA-0058G/V2 |
ENLF-36-SSD | Rc3/4" | 3.6 | 129 | 30 | 14 | 22 | 55 | 220-230/1/50 | 0.62 | 0.83 | ENG-AO-0058G/V2 | ENG-AA-0058G/V2 |
ENLF-40-SSD | Rc3/4" | 4.0 | 143 | 30 | 14 | 22 | 55 | 220-230/1/50 | 0.65 | 0.87 | ENG-AO-0080G/V2 | ENG-AA-0080G/V2 |
ENLF-60- PD | Rc1- 1/2" | 6.5 | 232 | 30 | 23 | 36 | 78 | 220-230/1/50 | 1.40 | 1.88 | ENG-AO-0145G/V2 | ENG-AA-0145G/V2 |
ENLF-80- PD | Rc1- 1/2" | 8.8 | 314 | 30 | 23 | 36 | 80 | 220-230/1/50 | 1.40 | 1.88 | ENG-AO-0145G/V2 | ENG-AA-0145G/V2 |
ENLF- 100- PD | Rc1- 1/2" | 11.0 | 393 | 30 | 23 | 36 | 85 | 220-230/1/50 | 1.85 | 2.48 | ENG-AO-0220G/V2 | ENG-AA-0220G/V2 |
ENLF- 120- PD | Rc2" | 13.0 | 464 | 39 | 28 | 41 | 130 | 220-230/1/50 | 2.30 | 3.08 | ENG-AO-0220G/V2 | ENG-AA-0220G/V2 |
ENLF- 150- PD | Rc2" | 17.0 | 607 | 39 | 28 | 41 | 140 | 220-230/1/50 | 3.03 | 4.06 | ENG-AO-0330G/V2 | ENG-AA-0330G/V2 |
ENLF-200- PD | Rc2" | 22.0 | 786 | 39 | 28 | 41 | 150 | 380-400/3/50 | 3.10 | 4.16 | ENG-AO-0330G/V2 | ENG-AA-0330G/V2 |
ENLF-250- PD | Rc2- 1/2" | 27.0 | 964 | 39 | 32 | 63 | 250 | 380-400/3/50 | 3.63 | 4.87 | ENG-AO-0430G/V2 | ENG-AA-0430G/V2 |
ENLF-300- PD | Rc2- 1/2" | 33.0 | 1179 | 39 | 32 | 63 | 260 | 380-400/3/50 | 4.40 | 5.90 | ENG-AO-0620G/V2 | ENG-AA-0620G/V2 |
ENLF-350- PD | Rc2- 1/2" | 37.0 | 1321 | 39 | 32 | 63 | 270 | 380-400/3/50 | 5.10 | 6.84 | ENG-AO-0620G/V2 | ENG-AA-0620G/V2 |
ENLF-400- PD | DN100 | 45.0 | 1607 | 49 | 44 | 69 | 500 | 380-400/3/50 | 6.13 | 8.22 | ENG-AO-0620G/V2 | ENG-AA-0620G/V2 |
ENLF-500- PD | DN100 | 55.0 | 1964 | 49 | 44 | 69 | 510 | 380-400/3/50 | 6.90 | 9.25 | ENG-AO-0830F/V2 | ENG-AA-0830F/V2 |
ENLF-600- PD | DN100 | 65.0 | 2321 | 49 | 44 | 69 | 550 | 380-400/3/50 | 8.34 | 11.18 | ENG-AO- 1000F/V2 | ENG-AA- 1000F/V2 |
